What products can the vertical mesh bag packaging machine handle?

The vertical mesh bag packaging machine is suitable for round and irregular-shaped produce including garlic, onions, potatoes, sweet potatoes, ginger, citrus fruits, apples, oranges, eggs, and various root vegetables. Bag weight ranges from 0.5kg to 5kg depending on the model and mesh size selected.

How many bags per minute can the vertical mesh bag machine produce?

The SY-WDJ2500 vertical mesh bag packaging machine achieves 20-35 bags per minute depending on bag weight and product size. Lighter 0.5kg bags reach approximately 30-35 bags/min, while heavier 3-5kg bags operate at 20-25 bags/min.

Does the vertical mesh bag machine automatically attach labels?

Yes. The SY-WDJ2500 is equipped with an automatic label attachment system that prints and sticks product labels (weight, origin, grade) onto each mesh bag during the packaging process. Label position and content are adjustable via the touch screen.

Can the vertical mesh bag machine be customized for different bag sizes?

Yes. The machine supports quick adjustment of bag length and width using the 99-recipe memory function. Changing from 0.5kg garlic bags to 3kg onion bags takes only 2-3 minutes with no tool required. Film width options range from 250mm to 350mm.

Vertical Mesh Bag Packaging Machine | 20-35 Bags/Min - ZSYAN China

1/4

Vertical Mesh Bag Packaging Machine | 20-35 Bags/Min - ZSYAN China

QR code

WeChat

Sina Weibo

QQ space

Douban

Baidu Post Bar

Auto bagging for garlic, onion & potato at 20-35 bags/min. Automatic labeling & tying. Request specs & quote from ZSYAN China manufacturer.

Parameter

Packaging speed ： 20-35b/min

Bag length accuracy ： ±15mm

Touch screen ： 7-inch color touch screen

Power requirements ： Single phase AC220V/50HZ, 60HZ

Storable program ： 99

Language ： Multiple languages

17788746792

Message

Detail

Vertical Mesh Bag Packaging Machine — Auto Bagging for Garlic, Onion & Potato | ZSYAN

ZSYAN vertical mesh bag packaging machine is the core product for automated packaging of fresh produce including garlic, onions, potatoes, ginger, citrus fruits, and other round or irregular-shaped agricultural products into mesh bags. The machine integrates automatic film feeding, bag forming, filling, sealing, label attaching and cutting in a single continuous operation.

Key specifications: packaging speed 20-35 bags per minute, bag weight range 0.5-5kg, mesh bag sizes from 0.5kg to 5kg customizable, film width up to 350mm. The machine features a 7-inch color touch screen, 99 recipe memory, automatic tension control, and real-time weight monitoring with auto alarm for out-of-spec bags.

Built with 304 food-grade stainless steel frame and contact parts, the SY-WDJ2500 vertical mesh bag packaging machine is suitable for food processing plants, agricultural cooperatives, export packaging companies, and supermarket chains. CE certified, ISO 9001 compliant, exported to 50+ countries across Southeast Asia, Middle East, Africa, and South America.

Application scenarios: garlic packaging (0.5kg/1kg/2kg bags), onion packaging, potato and sweet potato packaging, citrus and apple packaging, ginger and turmeric packaging, egg packaging in mesh bags, and various root vegetable packaging operations.

Scope of application

Wide Range of Vacuum & Mesh Bag Packaging Applications:
- Vacuum Packaging: quail eggs, soy eggs, spicy food, ham sausage, jelly, small potatoes, vacuum-packed meat products
- Granular Products: hardware parts, nuts, seeds, beans, rice grains, sugar, salt
- Snacks & Nuts: chestnuts, red dates, peanuts, passion fruit, almonds, cashews, sunflower seeds
- Daily Necessities: sponges, dish brushes, scouring pads, bath accessories
- Agricultural Products: onions, garlic, citrus fruits, root vegetables
- Toys & Small Items: toy balls, plastic components, small hardware

Compatible with various mesh bag materials: PP mesh, PE mesh, jute mesh, non-woven fabric bags, and vacuum packaging films.

Product advantages

Key Advantages:
- Automatic Bag Making: Built-in film feeding and bag forming system, producing vertical mesh bags on the fly without pre-made bags
- Smart Alarm System: Real-time monitoring with automatic alerts for no-net, no-label, and no-wire conditions, preventing production waste
- Servo Label Delivery: Precision servo-controlled label feeding ensures accurate label positioning and consistent bag length
- Precise Length Control: Digital control system with high positioning accuracy, ensuring uniform bag dimensions every time
- Vacuum Packaging Compatible: Supports vacuum packaging film for extended product shelf life and premium presentation
- 7-Inch Touch Screen HMI: Intuitive PLC control with multiple language support, easy parameter adjustment and 99 storable recipes
- 304 Stainless Steel Construction: Food-grade contact parts meeting hygiene standards, easy to clean and maintain
- Modular Quick-Change Design: Fast component replacement without tools

Technical Specifications

ZSYAN vertical mesh bag packaging machine features servo motor drive, 7-inch color touch screen, and automatic bag making system. Packaging speed: 10-30 bags/min. Compatible with mesh bags and vacuum packaging films. Ideal for quail eggs, ham sausages, chestnuts, red dates, peanuts, and other products requiring vacuum or mesh bag packaging.

Product Name	1000g Vertical packaging machine	5000g Vertical packaging machine
Specification Model	SY-WDJ2500A	SY-WDJ5000A
Material	304 stainless steel	304 stainless steel
Packaging scope	200-1000g	200-5000g
Packaging speed	20-35b/min	20-35b/min
Bag length accuracy	±15mm	±15mm
Bucket specifications	150	190
Touch screen	7-inch color touch screen	7-inch color touch screen
Drive Type	Servo motor+variable frequency motor	Servo motor+variable frequency motor
Storable program	99	99
Language	Multiple languages	Multiple languages
Power requirements	Single phase AC220V/50HZ, 60HZ	Single phase AC220V/50HZ, 60HZ
Power consumption	1-5KW	1-5KW
Package dimensions	18001900900mm	18001900900mm
Machine weight	500kg	700kg
